Contact Sensor AAA (Zigbee) EN RSH-DS10
User Manual
English
Door/Window Sensor detects the open/close status of household facilities like doors, windows, and drawers.
You can search "Smart Life" in the mobile application store to install the App
Slide down the rear cover to open the device case. Then put a battery into the product.
Long press the reset button for 10 seconds and release, the device is ready to be paired when the green LED flashes.
This button not only acts as a reset button, but also triggers a series of processes.
1.Open the App and click the "+" button on the upper right corner, then click the sensor button in the "Add a device" panel and follow the instructions inthe app to pair the device.
2. After the sensor is paired, you can long press the device button on the main page of the App to inspect the sensor status and view alarm history
To install the sensor:
1. Remove the protective films on the backside of both the sensor unit and the magnet.
2. During installation, align the mark of the main device and the magnet.
3. Install the product on a door or window with the main device fixed on the door or window frame.
The automation function is available in the App to connect different devices. Each automation contains a series of trigger conditions and target actions.The target actions will be automatically triggered when the conditions are met.
To set up an automation, click the “+” button in the upper right corner of the automation page. You can use the sensor as a trigger condition and createtarget actions with other appliances.
Do not install the product outdoors, on an unstable base, or anywhere unprotected from the rain.
Do not place magnetic metals or other objects near the product to maximize signal strength. When pasting and installing, it is necessary to ensure that the installation place of the sensor should be smooth, flat, dry, and clean.
Sensor dimensions : 51.2 x 51.2 x 12.6 mm
Sensor weight: 20g
Magnet dimensions: 34.5 x 7.6 x 12.4 mm
Magnet weight: 6g
Wireless protocol: Zigbee
Working voltage: DC 3V
Battery type: CR2032
If you have any questions or concerns about your HIMOJO device, please do not hesitate to contact us via email at support By scan QRCode . Our dedicated customer support team is here to assist you and ensure that you have the best experience with our product. We are committed to providing you with the highest level of customer service and look forward to hearing from you.
